DAT General Chemistry: Dimensional Analysis and Significant Figures

DAT High-Yield Concept

Dimensional Analysis: Orient conversion factors so unwanted units cancel algebraically, leaving only the target unit in the final answer.
Exact vs. Measured Numbers: Measured values carry experimental uncertainty and limit significant figures. Defined unit conversions (e.g., $\pu{1 in} = \pu{2.54 cm}$ ), stoichiometric ratios, and counts of discrete items are exact numbers with infinite significant figures.
Multiplication/Division Rule: The final result retains the same total number of significant figures as the term with the fewest significant figures.
Addition/Subtraction Rule: The final result is rounded to the same decimal place (least precise place value) as the term with the fewest decimal places.

Dimensional Analysis and Conversion Factor Chains

Dimensional analysis (also known as the factor-label method) treats units as algebraic terms. To convert a physical quantity from one unit to another, multiply by equivalence ratios (conversion factors) equal to 1, ensuring unwanted units cancel out.

Conversion factors used to convert between Metric and English systems of measurements and units. The quantities involved are mass, length and volume. (Source: Emeka Udenze · CC BY-SA 4.0 · Wikimedia Commons)

For complex multi-step problems, build and chain conversion factors sequentially so that each denominator cancels the numerator of the preceding term.

The conversion-factor chain: set it up so the units cancel — Dimensional analysis works because a conversion factor is a fraction whose top and bottom are the same physical quantity, so the fraction equals one and multiplying by it changes the units without changing the quantity. Write the chain so that each unit you want to get rid of appears once on top and once underneath, and it cancels. Miles cancel against miles, kilometres against kilometres, hours against hours, and metres over seconds is all that is left, which is exactly the unit asked for. Set the whole chain up before multiplying anything: if the units do not cancel to what you want, the setup is wrong, and no amount of arithmetic will fix it.

Worked Example: Conversion-Factor Chain
Problem: What is the mass in grams of

\pu{45.0 mL}

of ethanol (

\ce{C2H5OH}

) if its density is

\pu{0.789 g/mL}

?
Solution: Set up the dimensional analysis chain:

\pu{45.0 mL C2H5OH} \times \frac{\pu{0.789 g C2H5OH}}{\pu{1.00 mL C2H5OH}} = \pu{35.505 g C2H5OH}

Because both

\pu{45.0 mL}

and

\pu{0.789 g/mL}

contain 3 significant figures, the final mass rounds to

\pu{35.5 g}

.
DAT Exam Trap: When converting squared or cubed units (e.g.,

\pu{cm3}

\pu{m3}

), raise both the number and the unit in the conversion factor to that power. For instance,

\pu{1 m3} = (\pu{100 cm})^3 = \pu{10^6 cm3}

, not

\pu{100 cm3}

Exact vs. Measured Quantities and Identifying Significant Figures

Every measured quantity contains experimental uncertainty. When reading laboratory equipment, record all certain digits plus one estimated digit.

Estimating a digit in measurements. This product was funded by a grant awarded by the U.S. Department of Labor's Employment and Training Administration. The product was created by the grantee and does not necessarily reflect the official position of the U.S. Department of Labor. The Department of Labor makes no guarantees, warranties, or assurances of any kind, express or implied, with respect to such information, including any information on linked sites and including, but not limited to, accuracy of the information or its completeness, timeliness, usefulness, adequacy, continued availability, or ownership. (Source: Community College Consortium for Bioscience Credentials · CC BY 4.0 · Wikimedia Commons)

Significant figures include all known digits plus the estimated digit. Non-zero digits and interior (trapped) zeros are always significant. Leading zeros are never significant. Trailing zeros are significant only if a decimal point is explicitly present in the number.

Example of significant figures (Source: https://commons.wikimedia.org/wiki/User:Swpb · CC BY-SA 4.0 · Wikimedia Commons)

In contrast, exact numbers contain no uncertainty and possess infinite significant figures. Exact numbers include counted integers (e.g., 6 test tubes), defined metric/English relationships (e.g., $\pu{1000 mL} = \pu{1 L}$ ), and stoichiometric coefficients from balanced chemical equations such as $\ce{2H2 + O2 -> 2H2O}$ .

Feature	Measured Quantities	Exact Quantities
Source	Laboratory instruments (balances, burets, rulers)	Definitions, counting, chemical equation coefficients
Uncertainty	Contains uncertainty in the final digit	Zero uncertainty
Significant Figures	Limited by tool precision (e.g., $\pu{25.00 mL}$ has 4 sig figs)	Infinite ( $\infty$ ); never limits calculation precision
DAT Examples	$\pu{12.31 g}$ reagent mass, $\pu{1.05 atm}$ pressure	$\pu{12 in} = \pu{1 ft}$ , reaction mole ratios

Applying Significant-Figure Rules to Calculated Results

Calculated outputs must reflect the precision of the initial physical measurements:

Multiplication and Division: Round the result to match the term with the fewest total significant figures.
Addition and Subtraction: Round the result to match the term with the fewest decimal places (least precise place value).
Mixed Operations: Follow operational order, track the limiting significant figures at each step, but carry unrounded numbers through intermediate calculations to avoid premature rounding errors.

Sig Fig Rule Mnemonic:
Multiplication / Division = Most restrictive TOTAL digits.
Addition / Subtraction = Aligned DECIMAL places.

Worked Example: Operations with Significant Figures
Problem: Determine the density of an unknown liquid if an empty beaker weighs

\pu{25.10 g}

, the beaker with liquid weighs

\pu{37.524 g}

, and the liquid volume is

\pu{10.0 mL}

.
Step 1 (Subtraction for mass):

\pu{37.524 g} - \pu{25.10 g} = \pu{12.424 g}

Subtraction is limited to 2 decimal places (from

\pu{25.10 g}

), giving

\pu{12.42 g}

(4 significant figures).
Step 2 (Division for density):

\text{Density} = \frac{\pu{12.424 g}}{\pu{10.0 mL}} = \pu{1.2424 g/mL}

Division compares total sig figs:

\pu{12.42 g}

(4 sig figs) vs.

\pu{10.0 mL}

(3 sig figs). The final result rounds to 3 significant figures:

\pu{1.24 g/mL}

.
DAT Exam Trap: Rounding intermediate values during multi-step calculations can compound rounding error. Keep extra decimal digits during intermediate steps and apply significant figure rules only at the final step.

Critical Thinking Questions

A student measures $\pu{15.0 mL}$ of water in a graduated cylinder and adds it to a beaker containing $\pu{0.0025 g}$ of salt. Which measurement limits the sig figs of the total combined mass, and why?
Why does converting $\pu{5.0 cm3}$ to $\pu{m3}$ require dividing by $10^6$ rather than $100$ ? Explain using conversion factor chaining.
In the reaction $\ce{N2 + 3H2 -> 2NH3}$ , why does the stoichiometric ratio $\frac{\pu{2 mol NH3}}{\pu{1 mol N2}}$ not limit the significant figures of a calculated product mass?
